Gocator Line Profile Sensors: User Manual

Gocator Web Interface • 259

Measurement Illustration

Length

Determines the distance between the selected features

along the Y axis.

Height

Determines the distance between the selected features

along the Z axis.

Distance

Determines the direct, Euclidean distance between the

selected features.
