363-206-204
Powering, Verification, and Circuit Pack Installation
Issue 9 October 1998
4-35
SYSCTL Switch 4 Notes
:
1. The TBOS terminator is the physical termination of the telemetry daisy-chain. Set the
TBOS terminator for "last" if the shelf is the last shelf position on the telemetry
daisy-chain at the CO, where the initial link is made.
2. Set the TBOS terminator for "not last" if the shelf is not the last shelf on the telemetry
daisy-chain.
3. Set all RT applications as "not last".
Figure 4 -7. BBG5 (SYSCTL) Option Switches (Sheet 5 of 5)
Switch 4 Settings
TBOS Terminator
Shelf Location Sec 1 Sec 2
Not Last OFF OFF
Last ON OFF
