Lucent Technologies DDM-2000 OC-3 - Page 28

xxviii
Issue 9 October 1998
Figures
8 Releases 9 and 11 Installation Tests
Figure 8-1. Installation Test Connections 8-29
Figure 8-2. DDM-2000 User Panel 8-30
Figure 8-3. 27G-U OLIU 8-31
Figure 8-4. Establishing Cross-Connects 8-32
9 Release 13 (TARP) Installation Tests
Figure 9-1. Installation Test Connections 9-28
Figure 9-2. DDM-2000 User Panel 9-29
Figure 9-3. 27G-U OLIU 9-30
Figure 9-4. Establishing Cross-Connects 9-31
10 Operational Tests
Figure 10-1. Remote Terminal Miscellaneous (Environmental) Discrete
Functions (Releases 6 and 7). 10-22
Figure 10-2. Central Office Terminal Miscellaneous (Environmental) Discrete
Functions (Releases 6 and 7).10-23
Figure 10-3. Miscellaneous (Environmental) Discrete Functions (Releases 8, 9, 11 and 13). 10-24
11 Troubleshooting
Glossary
Index
