Lucent Technologies DDM-2000 OC-3 Installation Manual

363-206-204
Release 13 (TARP) Installation Tests
Issue 9 October 1998
9-15
NOTE
:
After fiber connection is completed around the ring, continued flashing of
the fault LED on 22 Type OLIU circuit packs may indicate incorrect connec-
tions.
To obtain a map of the SONET network to verify fiber connections around
the ring, at the first site issue the command rtrv-map-net;
Using Figure 9-1 (or an adapted version to match your ring) at the first site,
verify the following:
For Release 13 the form of the response to rtrv-map-net is
Location Slot Connector <--> Location Slot Connector
First Site M1 OUT <--> Second Site M2 IN
First Site M1 IN <--> Second Site M2 OUT
Second Site M1 OUT <--> Third Site M2 IN
Second Site M1 IN <--> Third Site M2 OUT
Third Site M1 OUT <--> Fourth Site M2 IN
Third Site M1 IN <--> Fourth Site M2 OUT
Fourth Site M1 OUT <--> First Site M2 IN
Fourth Site M1 IN <--> First Site M2 OUT
r
trv-map-network: COMPLD
/* Network Map for DDM4
=====================================================================
TID Product Type Level 2 IS NSAP
=====================================================================
DDM4 DDM-OC3
3
9840F 80 000000 0000 0000 0001 08006A1AE231 00
DDM3
3
9840F 80 000000 0000 0000 0001 08006A1AE2B1 00
DDM8
3
9840F 80 000000 0000 0000 0001 08006A1A000C 00
DDM9
3
9840F 80 000000 0000 0000 0001 08006A1ABF5A 00
FR5 39840F 80 000000 0000
0
000 0001 08006A1AE428 00
FR6 39840F 80 000000 0000
0
000 0001 08006A1AE27E 00
FR7 39840F 80 000000 0000
0
000 0001 08006A1AA76A 00
FT10 39840F 80 000000 0000
0
000 0001 08006A062630 00
FT2 Y 39840F 80 000000 0000
0
000 0001 08006A061069 00
*/
