9-16
Issue 9 October 1998
363-206-204
Release 13 (TARP) Installation Tests
7. To obtain a neighbor map to verify fiber connections to shelves directly con-
nected to the first site and which OLIU they are connected through, at the
first site issue the command
rtrv-map-net;
Using Figure 9-1 (or an adapted version to match your ring) at the first site
verify the following:
For Release 13 the response to
rtrv-map-neighbor
is
8. Continue around the ring verifying that the Neighbor Map "connected
through" indications at each node match the indicated fiber connections of
Figure 9-1 (or your individual map). If not, correct the fiber connections.
9. A Network Map containing all nodes in the network should be obtainable
from any node in the ring.
Test Fiber Connections
Alarms associated with fiber disconnects shall be tested. The following test should
be performed at each site. Refer to Figure 9-1.
1. At the first site disconnect OLIU Main-1 Out. Use the ‘
rtrv-alm
’ com-
mand to check for the following alarm (other alarms may exist) to verify
proper fiber connection:
ne-acty main-1 ------------- inc.OC3 FERF
rtrv-map-neighbor: COMPLD
/* Neighbor Map for DDM4
=====================================================================
TID Connected Thru Product Type Level 2 IS
SAP
=====================================================================
DDM4 DDM-OC3
39840F 80 000000 0000 0000 0001 08006A1AE231 00
DDM8 main-1
39840F 80 000000 0000 0000 0001 08006A1A000C 00
DDM3 main-2
39840F 80 000000 0000 0000 0001 08006A1AE2B1 00
