Manitowoc 2250 Service Maintenance Manual

Reference Only
Manitowoc Published 07-19-16, Control # 249-01 3-15
2250 SERVICE/MAINTENANCE MANUAL ELECTRICAL SYSTEM
3
P12-30 DO-12 Grd CAN System Ground Ground
P12-31 CANH CAN-Hi Data Line (CraneSTAR) N/A
P12-32 CANL CAN-Low Data Line (CraneSTAR) N/A
P12-33 DI-19 Diesel Particulate Filter (DPF) Regeneration Disable 24 Volts Nominal
P12-34 DI-21 Diesel Particulate Filter (DPF) Regeneration Initiate 24 Volts Nominal
P12-37 DO-13 Grd CAN System Ground Ground
P12-38 DO-14 Grd CAN System Ground Ground
P2 Data Download/Upload Receptacle—Front Console Master Node
P2-1 Data TX1 RX1-35 Receive data from Crane Controller Variable 6 to 7 Volts Nominal
P2-2 Data RX1 TX1-34 Transmit data to Crane Controller Variable 6 to 7 Volts Nominal
P2-3 Data X Load Indicator Data Download N/A
P2-4 Logic Grd Ground Ground
Pin Function Type Description
Test Voltage
(DC unless otherwise specified)
