Manitowoc 2250 Service Maintenance Manual

Reference Only
Manitowoc Published 07-19-16, Control # 249-01 10-61
2250 SERVICE/MAINTENANCE MANUAL TROUBLESHOOTING
10
Test 26—Actuating the Solenoid Valve Manual Overrides
To check that a solenoid valve or system valve is operating
correctly, start the engine and actuate the manual valve
override (2). Observe the following:
• Hydraulic brake valves (1) have an override push button
in the center of a black nut.
• If the valve is operating correctly, the valve shifts to
perform the control function.
P924
P974
1
2
3
2
FIGURE 10-29
Item Description
1 Hydraulic Brake Valve (qty varies)
2 Valve Override
3 Auxiliary System Disable Valve (qty varies)
