TROUBLESHOOTING 2250 SERVICE/MAINTENANCE MANUAL
10-38
Published 07-19-16, Control # 249-01
Test 5—Cleaning and Adjusting the Engine RPM Transducer
To clean and adjust the engine RPM transducer (2), perform
the following procedure.
1. Loosen the lock nut (3) and remove the threaded
transducer from the flywheel housing (1).
2. Clean any metallic debris from the magnetic pickup on
the transducer with a cleaning solvent.
3. Reinstall the transducer so the magnetic pickup makes
contact with the flywheel.
4. Back the flywheel off 1/2 turn and secure the lock nut.
P933
1
2
3
FIGURE 10-6
Item Description
1 Flywheel Housing
2 RPM Transducer
3 Lock Nut
