Manitowoc 2250 - Page 213

Reference Only
Manitowoc Published 07-19-16, Control # 249-01 4-9
2250 SERVICE/MAINTENANCE MANUAL BOOM
4
Item Description
1 Luffing Jib Butt
2 Angle Indicator Sending Unit (qty 1 or 2)
3 Protractor Level
4 Punch Marks
5 Scribed Line
6 Boom Butt
FIGURE 4-6
