Manitowoc 2250 Service Maintenance Manual

Reference Only
Manitowoc Published 07-19-16, Control # 249-01 1-17
2250 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
Item Description
1 Boom Hoist Brake Solenoid Valve
2 Return Oil Check Valve (qty 3)
3 Drum Brake Relay Valve (qty 2)
4 Drum Brake Lever
5 Drum Brake Quick-Release Valve (qty 2)
6 Adapter Frame Connecting Pin Cylinder (qty 4)
7 Hydraulic Swivel
8 Hydraulic Disconnect Sequence Valve
9 Hydraulic Disconnect Pump (electric with integral oil tank)
10 Shipping Cover
11 Hydraulic Disconnect Travel Cylinder
12 Adapter Frame Coupling Plate (outboard side)
Adapter Frame Coupling Plate (inboard side)
13 Hydraulic Disconnect Coupling Cylinder
14 Disconnect (typical)
15 Adapter Frame Junction Box
16 Luffing Hoist Brake Solenoid Valve
17 Travel 2-Speed Solenoid Valve
18 Travel Brake Solenoid Valve
19 Not Used
20 Swing Brake Solenoid Valve
21 Left Crawler Pins Solenoid Valve (top retract / bottom extend)
22 Right Crawler Pins Solenoid Valve (top retract / bottom extend)
23 Boom Hinge Pins Solenoid Valve (top retract / bottom extend)
24 Boom Butt Handling Solenoid Valve (top retract / bottom extend)
25 Rigging Winch Solenoid Valve (top pay out / bottom haul in)
FIGURE 1-7 continued
