Reference Only
INTRODUCTION 2250 SERVICE/MAINTENANCE MANUAL
1-70
Published 07-19-16, Control # 249-01
RF-44
HS-33
Coupling Cylinders Engaged
Sleeve Plate
Coupling Plate
(300 psi)
Motor
21 bar
(200 psi)
14 bar
Frame
HS-34
Frame Cylinder Extended
Coupling Cylinders Disengaged
Frame Cylinder Retracted
RF-45
HS-33
Sleeve Plate
Coupling Plate
Motor
Frame
HS-34
FIGURE 1-43
14 bar
(200 psi)
21 bar
(300 psi)
