Manitowoc MLC650 Service Maintenance Manual

Reference Only
Manitowoc Published 09-09-16, Control # 229-09 3-43
MLC650 SERVICE/MAINTENANCE MANUAL ELECTRICAL SYSTEM
3
PC2-5 ODH3A02 Power to Right and Left VPC Actuator Motor Speed Sensors
24 V
DC
PC2-6 ODH3A04 VPC Tray Diverter Solenoid
0V
DC
Off, 24 V
DC
On
PC2-7 ODH3A07 VPC Alarm
0V
DC
Off, 24 V
DC
On
PC2-8 ODH3A10 Left Stowage Cylinder Extend Solenoid
0V
DC
Off, 24 V
DC
On
PC2-9 ODH3A12 Right Stowage Cylinder Extend Solenoid
0V
DC
Off, 24 V
DC
On
PC2-10 OPH3A15 Right Rear Jack Retract Solenoid
0V
DC
Off, 24 V
DC
On
PC2-11
+U
B
Supply Power for Control Module Outputs
24 V
DC
PC2-12 OS85H Not Used—For Possible Future Expansion
8.5 V
DC
PC2-13 IACV19 Drum 4 Pressure Transducer
4mA @ 0psi
20 mA @ 7,500 psi
PC2-14 IACV20 Drum 1 Pressure Transducer
4mA @ 0psi
20 mA @ 7,500 psi
PC2-15 ODH3A01
Power Bus:
• Drums 1, 3, 4, and 5 Pressure Transducers
• VPC Actuator Retract Pressure Transducer
24 V
DC
PC2-16 ODH3A06 VPC Alarm
0V
DC
Off, 24 V
DC
On
PC2-17 ODH3A09 VPC Rear Warning Lights
0V
DC
Off, 24 V
DC
On
PC2-18 OPH3A14 Right Rear Jack Extend Solenoid
0V
DC
Off, 24 V
DC
On
PC2-19 OPH3A17 Not Used—For Possible Future Expansion
0V
DC
PC2-20
+U
B
Supply Power for Control Module Outputs
24 V
DC
PC2-21 OS85L Not Used—For Possible Future Expansion
0V
DC
PC2-22 IACV21 VPC Actuator Retract Pressure Transducer
4mA @ 0psi
20 mA @ 7,500 psi
PC2-23 No Connection
PC2-24 ODH3A03 VPC Actuator Brake
0V
DC
Off, 24 V
DC
On
PC2-25 ODH3A05 VPC Tray Brake
0V
DC
Off, 24 V
DC
On
PC2-26 ODH3A08 VPC Front Warning Lights
0V
DC
Off, 24 V
DC
On
PC2-27 ODH3A11 Left Stowage Cylinder Retract Solenoid
0V
DC
Off, 24 V
DC
On
PC2-28 ODH3A13 Right Stowage Cylinder Retract Solenoid
0V
DC
Off, 24 V
DC
On
PC2-29 OPH3A16 ACC System Prop Relief
0V
DC
Off, 24 V
DC
On
Pin I/O Network Function Voltages
