0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 139 / 231
Max Wheel diameter
Input Range: 350 – 450 mm
Maximum useable diameter of the grinding wheel to grind the workpiece
Min Wheel diameter
Input Range: 350 – 450 mm
Minimum useable diameter of the grinding wheel to grind the workpiece
Active Wheel diameter
This is a read only display field and informs you of the active wheel diameter in machine currently
Max Wheel speed
Input Range: 500– 3000 rpm
Maximum safe speed of the grinding wheel.
Dress set at helix
Input selection: YES/NO
Select YES if the dresser system is set to helix.
With fixed helix (0°) dresser system always set to NO.
When using dressing disc or single point diamond dressing media then this field must be set to NO.
