Matrix 0850 - Page 19

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 19 / 231
Edition: 08/2013
RH rear perspective view of machine
7
RH side machine service access door
8
Electrical Control Cabinet with AC unit fitted
to door panel
9
Main electrical power isolator switch
10
Coolant system
11
Stage 1 coolant oil filtration
12
Stage 2 coolant oil filtration
13
High pressure lift pump
14
Coolant system control panel
9
8
10
11
12
13
14
7
