Matrix 0850 - Page 20

0850/0850-T1 User Manual
Matrix Machine Tool (Coventry) Limited 20 / 231
Edition: 08/2013
LH rear perspective view of machine
15
LH side machine service access door
16
Machine rear service access doors
17
Operator/Setter sliding access doors (for wheel and dressing tool change)
18
Workhead chuck pneumatic services control panel
19
Return coolant oil sub-tank
20
Grinding and dressing spindles chiller unit
Coolant system view (rear of machine)
15
18
17
16
19
20
9
