27 - 82
27.4 Ethernet Connection
27.4.10 CNC Side Settings
(2) CNC side parameter setting
Confirm the CNC side parameter setting with the settings of IP address, gateway address, subnet
mask and port No. by the 7-segment LED and rotary switch of the CNC side.
For details of the parameter setting operation, refer to the following.
MELDAS C6/C64 NETWORK MANUAL BNP-B2373 IV Setting the Ethernet IP Address
7-segment LED
Rotary switch
To Next Page
