30.3 Preparatory Procedures for Monitoring
30.3.1 Installing OS onto GOT
30.3.1 Installing OS onto GOT
Install the standard monitor OS, communication driver and option OS onto the GOT.
For the OS installation methods, refer to the following manual.
GT Designer2 Version Basic Operation/Data Transfer Manual
1 Check-mark a desired standard monitor OS, communication driver, option OS, and extended function
OS, and click the button.
Place a check mark in either box of the following items
under the Communication driver, according to the
connection type of the 1st GOT.
• When connecting to A/QnA/QCPU or a motion controller
CPU: A/QnA/QCPU, QJ71C24, MELDAS C6*
• When connecting to FXCPU: MELSEC-FX
Install
To Next Page
