31.2 Preparatory Procedures for Monitoring
31.2.1 Installing OS onto GOT
31 - 7
25
BAR CODE READER
CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL
FUNCTION
29
FA TRANSPARENT
FUNCTION
30
MULTIPLE-GT11
CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
31.2.1 Installing OS onto GOT
Install the option OS onto the GOT.
For the OS installation methods, refer to the following manual.
GT Designer2 Version Basic Operation/Data Transfer Manual
1 Check-mark a desired option OS (gateway function), and click the button.
Check the following under the Communication driver.
Depends on the connection type
Place a check mark in the box of the function used in Option OS.
Gateway (Server, Client)
Gateway (Mail)
Gateway (FTP)
Install
