31.2 Preparatory Procedures for Monitoring
31.2.3 Setting communication interface (Communication settings)
31 - 11
25
BAR CODE READER
CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL
FUNCTION
29
FA TRANSPARENT
FUNCTION
30
MULTIPLE-GT11
CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
*1 No setting is required for "Gateway" of the communication details setting.
*2 When using the mail send function:
Specify the "Timeout Time" after connection to the SMTP server. (However, the communication timeout time of
about one minute is fixed for the case where connection with the SMTP server is failed after starting mail
transmission.)
*3 To connect the GOT with the Ethernet module (Q Series) in the one-on-one relationship using a cross cable, set
[Timeout Time] to 6 sec. or longer.
*4 When using the mail send function:
Specify the time of transmission interval between one mail and the next mail when sending multiple mails.
Item Description Range
GOT NET No.
Set the network No. of the GOT.
<Default: 1>
1 to 239
GOT PC No.
Set the station No. of the GOT.
<Default: 1>
1 to 64
GOT IP Address
Set the IP address of the GOT.
<Default: 192.168.0.18>
0.0.0.0 to 255.255.255.255
GOT Port No.
(QJ71E71/AJ71(Q)E71)
*1
Set the GOT port No. for the connection with the Ethernet module.
<Default: 5001>
1024 to 5010, 5014 to 65534
(Except for 5011, 5012 and 5013)
GOT Port No.
(Ethernet Download)
Set the GOT port No. for Ethernet download.
<Default: 5014>
1024 to 5010, 5014 to 65534
(Except for 5011, 5012 and 5013)
Default Gateway
Set the router address of the default gateway where the GOT is
connected. (Only for communication via router)
<Default: 0.0.0.0>
0.0.0.0 to 255.255.255.255
Subnet Mask
Set the subnet mask for the sub network. (Only for connection via
router)
If the sub network is not used, the default value is set.
<Default: 255.255.255.0>
0.0.0.0 to 255.255.255.255
Retry
Set the number of retries to be performed when a communication
error occurs.
When receiving no response after retries, the communication
times out.
<Default: 3 Times>
0 to 5 Times
Startup Time
Specify the time period from the GOT startup until GOT starts the
communication with the PLC CPU.
<Default: 3 Sec>
3 to 255 Sec
Timeout Time
*2*3
Set the time period for a communication to time out.
<Default: 3 Sec>
3 to 90 Sec
Delay Time
*4
Set the delay time for reducing the load of the network/destination
PLC.
<Default: 0ms>
0 to 10000 ( 10 ms)
