5.2 Preparatory Procedures for Monitoring
5.2.3 Setting communication interface (Communication settings)
3 Switch setting
For details of each setting switch and LED, refer to the following manual.
GT15 MELSECNET/10 communication unit User’s Manual
(1) Network number setting switch
(2) Group number setting switch
*1 The GOT does not use the group number.
Specify "0".
(3) Station number setting switch
Network number setting
switch
Description Setting
Set the network No. of the MELSECNET/10 communication unit.
<Default: 001>
1 to 239
Group number setting switch Description Setting
Set the group No. of the MELSECNET/10 communication unit.
<Default: 0>
0: No group setting (fixed)
*1
Station number setting switch Description Setting
Set the station No. of the MELSECNET/10 communication unit.
Set to not duplicate other stations in the network.
<Default: 01>
1 to 64: GT15-75J71LP23-Z
1 to 32: GT15-75J71BR13-Z
