5 - 28
5.3 PLC Side Setting
5.3.1 Connecting to MELSECNET/H network module
4 [Communication settings] of GT Designer2
[Communication Settings] of GT Designer2
For the setting method of [Communication Settings] of GT Designer2, refer to the
following.
Section 5.2.3 Setting communication interface (Communication settings)
5 Setting of the MELSECNET/10 communication unit
Setting of the MELSECNET/10 communication unit
For the setting method of the MELSECNET/10 communication unit, refer to the
following.
Section 5.2.3 Setting communication interface (Communication settings)
Item Setting (Use default value.)
Retry 3 Times
Timeout Time 3 Sec
Item Setting
Network number setting switch 1: Network No.1
Group number setting switch 0: No group setting (fixed)
Station number setting switch 2: Station number 2
Mode setting switch 0: On-line (fixed)
