5 - 40
5.3 PLC Side Setting
5.3.3 Connecting to MELSECNET/10 network module (A Series)
3 [Network parameter] of GX Developer
(1) Network parameter
: Necessary : As necessary : Not necessary
*1 Specify the same network No. as that of the network number setting switch of the MELSECNET/10 network
module.
Item Setting
Setting necessity at GOT
connection
Network type MNET/10 (Controlling station) (fixed)
Start I/O No. 0000H
Network No.
*1
1
Total stations 2
Network range assignment Refer to (2)
Refresh parameters
(Use default value)
Interlink transmission parameters
Routing parameters
To Next Page
