6.3 PLC Side Setting
6.3.2 Connecting to CC-Link module (QnA Series)
6 - 29
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION TO CPU
4
COMPUTER LINK CONNECTION
5
MELSECNET/10 CONNECTION (PLC TO PLC NETWORK)
6
CC-Link CONNECTION (INTELLIGENT DEVICE STATION)
7
CC-Link CONNECTION (Via G4)
8
ETHERNET CONNECTION
(b) Station information setting
: Necessary : As necessary : Not necessary
*1 Specify the same number of occupied stations as that of the GOT.
When changing the network parameter
After writing the network parameter to the PLC CPU, operate the PLC CPU ether
turning OFF and then ON or resetting.
Item Setting
Setting necessity at GOT
connection
Station type Intelligent device station (fixed)
Exclusive station count
*1
Exclusive station 1
Reserve/invalid station select No setting
Intelligent buffer select (word) (Use default value.)
