Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
1 System configuration and connection conditions
*1 The destination connected with the twisted pair cable varies with the configuration of the applicable Ethernet
network system.
Connect to the Ethernet module, hub, transceiver or other system equipment corresponding to the applicable
Ethernet network system.
Connection conditions
System configuration
Number of GOTs distance
128
(recommended to
16 units or less)
100m or less
(max.)
QJ71E71/AJ71(Q)E71
Communication driver
Ethernet module
Twisted pair cable
3
2
1
MAX100m
*1
To Next Page
