9.1 System Configuration
9.1.3 Connecting to C200HS, C200H, C200H or CS1
9 - 11
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
When connecting to CS1
Connection conditions
System configuration
No. of GOTs Distance
1
15m or less
200m or less
MAX15m
RS-232 cable 1)
12
1
Serial communication module
5
MAX15m
RS-232 cable 1)
12
1
Serial communication board
9 10
MAX15m
RS-232 cable 1)
12
1
Serial communication board
10
MAX200m
RS-422 cable 1)
14
2
9.1 System Configuration
9.1.3 Connecting to C200HS, C200H, C200H or CS1
