15.1 System Configuration
15.1.5 Connecting to CP-9200SH
15 - 11
9
CONNECTION TO
OMRON PLC
10
CONNECTION TO
KEYENCE PLC
11
CONNECTION TO
SHARP PLC
12
CONNECTION TO
TOSHIBA PLC
13
CONNECTION TO
HITACHI PLC
14
CONNECTION TO
MATSUHSHITA PLC
15
CONNECTION TO
YASKAWAI PLC
16
CONNECTION TO
YOKOGAWA PLC
(3) Cable
*1 The RS-232 cable can be prepared by the user.( Section 15.2 Connection Cable)
Image No. Name Model name
RS-232 cable 3)
*1
• Between MEMOBUS module
(CN1 connection) and GOT
GT09-C30R20203-9P(3m)
RS-232 cable 5)
*1
• Between MEMOBUS module
(CN2 connection) and GOT
GT09-C30R20205-25P(3m)
