15.2 Connection Cable

The RS-232 cable or RS-422 cable used for connecting the GOT to the PLC should be prepared by the user.

The following provides connection diagrams for each cable, connector specifications and other information.

Model

Connection cable

RS-232 cable

(See Section 15.2.1)

RS-422 cable

(See Section 15.2.2)

PLC CPU

GL120

RS-232 cable 1)

GL130

CP-9300MS

(CP-9300MC compatible/non-compatible)

RS-232 cable 3)

CP-9200(H) RS-232 cable 1)

PROGIC-8

Connecting to port 1 RS-232 cable 1)

Connecting to port 2 RS-232 cable 2)

MP-920

RS-232 cable 1)

MP-930

MP-940 RS-232 cable 4) RS-422 cable 2)

MEMOBUS module

JAMSC-120NOM27100 RS-422 cable 1)

JAMSC-IF60

RS-232 cable 1)

JAMSC-IF61

JAMSC-IF612 RS-422 cable 1)

CP-217IF

CN1 connection RS-232 cable 1)

CN2 connection RS-232 cable 5)
