YOKOGAWA PLC
CONNECTION TO
YOKOGAWA PLC
16.1 System Configuration . . . . . . . . . page 16-2
This section describes the equipment and cables needed
when connecting a GOT to a YOKOGAWA PLC.
Select a system suitable for your application.
16.2 Connection Cable . . . . . . . . . . . . page 16-7
This section describes the specifications of the cables
needed when connecting a GOT to a YOKOGAWA PLC.
Check the specifications of the connection cables.
16.3 Preparatory Procedure for Monitoring
. . . . . . . . . . . . . . . . . . . . . . . . . page 16-13
This section provides the procedures to be followed before
performing monitoring in connection to a YOKOGAWA PLC.
The procedures are written on the step-by-step basis so
that even a novice GOT user can follow them to start
communications.
16.4 PLC Side Setting . . . . . . . . . . . . page 16-28
The PLC side settings for GOT connection are explained.
When checking the PLC side settings, refer to this section.
16.5 Precautions . . . . . . . . . . . . . . . . page 16-36
This section describes the precautions to observe when a
GOT is connected to a YOKOGAWA PLC.
Be sure to read this section when connecting the GOT to a
YOKOGAWA PLC.
