16.2 Connection Cable
16.2.1 RS-232 cable
16 - 9
9
CONNECTION TO
OMRON PLC
10
CONNECTION TO
KEYENCE PLC
11
CONNECTION TO
SHARP PLC
12
CONNECTION TO
TOSHIBA PLC
13
CONNECTION TO
HITACHI PLC
14
CONNECTION TO
MATSUHSHITA PLC
15
CONNECTION TO
YASKAWA PLC
16
CONNECTION TO
YOKOGAWA PLC
(3) RS-232 cable 3)
*1 GT15:CD, GT11:NC
2 Connector specifications
(1) GOT side connector
Use the following as the RS-232 interface and RS-232 communication unit connector on the GOT.
For the GOT side of the RS-232 cable, use a connector or connector cover applicable to the GOT
connector.
(a) Connector type
9-pin D-sub (male) inch screw fixed type
(b) Connector model
*1 For the confirmation method of GT15 hardware version, refer to the following manual.
GT15 User's Manual
(2) YOKOGAWA PLC side connector
Use the connector compatible with the YOKOGAWA PLC side module.
For details, refer to the following manual.
User's Manual for the YOKOGAWA PLC
GOT side
Cable connection and signal direction
YOKOGAWA product side
Signal name Pin No. Pin No. Signal name
CD/NC
*1
1 1FG
RD(RXD) 2 2SD
SD(TXD) 3 3RD
ER(DTR) 4 4RS
SG 5 5CS
DR(DSR) 6 6DR
RS(RTS) 7 7SG
CS(CTS) 8 20 ER
9
GOT
Hardware
version*1
Model Manufacturer
GT1595-X A 17LE-23090-27(D3CC) DDK Ltd.
GT1585-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-V
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B
17LE-23090-27(D3CC) DDK Ltd.
GT1575-VN
A
GT1572-VN
GT1565-V
GT1562-VN
GT11
GT15-RS2-9P
To Next Page
