17 - 4
17.1 System Configuration
17.1.1 Connecting to SLC500 Series
(3) Cable
*1 The RS-232 cable can be prepared by the user. ( Section 17.2 Connection Cable)
Image No. Name Model
RS-232 cable 1)
*1
• Between CPU and GOT
GT09-C30R20701-9S(3m)
RS-232 cable 2)
*1
• Between Adapter and GOT
(To be prepared by the user. Section 17.2 Connection Cable)
