17.1 System Configuration
17.1.2 Connecting to MicroLogix1000/1200/1500 Series
(3) Cable
*1 The RS-232 cable can be prepared by the user.( Section 17.2 Connection Cable)
Image No. Name Model name
RS-232 cable 3)
• Between CPU and GOT
(To be prepared by the user. Section 17.2 Connection Cable)
RS-232 cable 2)
*1
• Between Adapter and GOT
GT09-C30R20702-9P(3m)
To Next Page
