18 - 20
18.4 PLC Side Setting
18.4.1 Connecting to HMI Adapter
18.4 PLC Side Setting
SIEMENS PLC
For details of SIEMENS PLCs, refer to the following manuals.
USER’s Manual for the SIEMENS PLC
18.4.1 Connecting to HMI Adapter
1 Communication settings
Set the communication settings of HMI adapter by operating the GOT.
*1 Set the address without overlapping the address of other units.
Model name Reference
PLC CPU S7-200 Section 18.4.2
HMI Adapter 6ES7 972-0CA11-0XA0 Section 18.4.1
PC/PPI cable 6ES7 901-3BF20-0XA0 Section 18.4.2
Setting item PLC side settings
Transmission speed 9600bps, 19200bps, 38400bps
Data bit 8-bit (fixed)
Parity bit EVEN (fixed)
Stop bit 1-bit (fixed)
Adapter address
*1
1 to 31
Host address
*1
1 to 31
