19.5 Message Formats

19.5.4 Formats 3 to 6 (A compatible 1C frame)

(4) Address

Specifies the head No. of the device data to be read/written.

The data annotated in decimal is converted to a 5- or 7-digit ASCII code (Hex) and transmitted from

the upper digit.

For details of the device range that can be accessed, refer to the following.

Section 19.4 Device Data Area

(5) Number of points

Specifies the number of device data to be read/written. (Setting range: 1 to 40

The data notated in Hex is converted to a 2-digit ASCII code (Hex) and transmitted from the upper

digit.

(6) Year, month, day, hour, minute, second and day of the week data

Specifies year, month, day, hour, minute, second, and day of the week to be read/set to the GOT

clock data.

Data notated in decimal is converted to a 2-digit ASCII code (Hex) and transmitted from the upper

digit.

(1)Read clock data (TR) command

(2)Set clock data (TS) command

(7) Error Code

This is the response message at faulty communication appended with error contents.

Data notated in Hex is converted to a 2-digit ASCII code (Hex) and transmitted from the upper digit.

For details of error codes generated in formats 3 to 6 (A compatible 1C frame), refer to the

following:

Error code list

When connecting a microcomputer, etc. that uses the dedicated protocol of the A

series computer link module with the GOT

When connecting a microcomputer, etc. that uses the dedicated protocol of the A

series computer link module with the GOT, correct the commands to use and the

device range according to the specifications of GOT.
