22.1 System Configuration
22.1.1 Connecting to H-PCP-J
2 System equipment
(1) GOT
*1 Connect it to the RS-232 interface ( built into GOT).
(2) Temperature controller
is a product manufactured by RKC. For details of this product, contact RKC.
Image No. Name Model name
RS-232 interface
• For RS-232 Communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 Communication
GT15-RS2-9P
RS-422 conversion unit*1
• For RS-422 Communication
GT15-RS2T4-9P
RS-422/485 Communication
Unit
• For RS-422 Communication
GT15-RS4-9S
RS-422 interface
• For RS-422 Communication
(Built into GOT)
RS-422/485 Communication
Unit
• For RS-485 Communication
GT15-RS4-TE
Image No. Name Model name
Conversion connector FAX067
RS-232
RS-232
RS-232
RS-422/485
RS-422
RS-422/485
