NICE3000
new
User Manual
7 Function Code Table
- 173 -
7
Function
Code
Parameter Name Setting Range Default Unit Property Page
F5-33
Terminal program
control
Bit3: Elevator re emergency
requirement for Hong Kong
Bit4: Arrival gong disabled at night
Bit6: Door lock disconnected
at inspection switched over to
normal running
Bit7: Fault code not displayed on
the keypad
Bit8: Door open command
cancelled immediately at door
open limit
Bit9: Car stop and zero-speed
torque holding at abnormal brake
feedback
0 -
★
256
F5-34 Terminal state display
Monitoring of I/O terminals on
MCB
- -
●
213
F5-35 Terminal state display
Monitoring of I/O terminals on
CTB, CCB and HCB
- -
●
213
F5-36
Load cell input
selection
0: MCB digital input
1: CTB digital input
2: CTB analog input
3: MCB analog input
1 -
★
209
F5-37 X25 function selection 0: Invalid
4: Safety circuit signal
5: Door lock circuit signal
0 -
★
207
F5-38 X26 function selection 0 -
★
207
F5-39 X27 function selection 0 -
★
207
Group F6: Basic elevator parameters
F6-00
Top oor of the
elevator
F6-01 to 40 9 -
★
214
F6-01
Bottom oor of the
elevator
1 to F6-00 1 -
★
214
F6-02 Parking oor F6-01 to F6-00 1 -
★
217
F6-03 Fire emergency oor F6-01 to F6-00 1 -
★
221
F6-04 Elevator lock oor F6-01 to F6-00 1 -
★
223
F6-05 Service oors 1 0–65535 65535 -
★
214
F6-06 Service oors 2 0–65535 65535 -
★
214
F6-07
Number of elevators
in parallel/group mode
1–8 1 -
★
217
F6-08 Elevator No. 1–8 1 -
★
217
