Monarch nice3000 User Manual

NICE3000
new
User Manual 8 Description of Function Codes
- 259 -
8
◆
F6-40 Program Control Selection 1
Function Code Parameter Name Setting Range Default Unit Property
F6-40
Program control selection 1 0–65535 0 -
★
F6-40 is used to select program control functions. Each bit of the function code denes a function, as
described in the following table.
If a bit is set to 1, the function indicated by this bit is enabled; if this bit is set to 0, the function is disabled.
For details on how to view and set this function code, see the descriptions in section 8.21.1.
The functions dened by the binary bits of F6-40 are described in the following table.
Bit Function Description Default
Bit0 Disability function It is used to enable or disable the disability function. 0
Bit1 Soft limit function
When the up slow-down and down leveling signals are active and
the up leveling signal is inactive, the system considers that the up
limit is performed. It is the same for the down limit signal.
0
Bit2
JP16 input used as back
door selection
This function is enabled if the opposite door function is used.
When JP16 has input, the elevator opens only the back door.
When IP16 has no input, the elevator opens only the front door.
0
Bit3
JP16 input used as the back
door open signal
JP16 is used for the input of the back door open signal. 0
Bit4
Opening only one door
of opposite doors under
manual control
This function is enabled only in the opposite door control mode 2
(hall call independent, opposite-door manual control). In this case,
only one door opens each time while the other door must stay in
the door close limit state.
In group Fd, the HCB-B extended input includes "Single/Double
door selection". If this input is active, both doors open if there is a
car call.
0
Bit5 Timed elevator lock F6-38/F6-39 is valid only when this function is enabled. 0
Bit6 Manual door This function is used for the elevator with manual door. 0
Bit7 Reserved - 0
Bit8 Reserved - 0
Bit9
Disabling reverse oor
number clear
The system clears all the current car calls every time the elevator
changes the direction by default. When this function is enabled,
the function of clearing reverse oor numbers is disabled.
0
Bit10
Displaying next arriving oor
number
The next oor to be arrived at is displayed during elevator running. 0
Bit11 Responding to car calls rst The system responds to hall calls only after executing all car calls. 0
Bit12
Car call assisted command
in single door used as
disability function
You can set the auxiliary command terminal (CN8) on the CTB for
input of the disability calls (folding command not required).
0
Bit13
Folding command used as
disability function and back
door function
It is valid only when the function of Bit14 is enabled.
Bit13 = 1: Disability
Bit13 = 0: Back door
0
