2 - 52 MC909X Integrator Guide
Figure 2-66 Attaching Two Shelf Slides
For a four slot cradle, slide the cradle on to the slides, across both brackets.
Secure each cradle or charger to its slide using the two set screws provided.
Insert set screws
