Motorola MC909X - Setup; Connecting to the Mobile Computer

Getting Started 2 - 29
Setup
Connecting to the Mobile Computer
Figure 2-31 Modem Module Connection - Mobile Computer
Using the Correct Telephone Line Type
Use a standard analog phone line, as in most households. In an office, use a line connected to a fax machine or
modem. In a hotel, request a room with a standard phone line or data port. If necessary, check with the local phone
company or administrator to make sure you are using the right type of line before sending data.
3
D
E
F
2
A
B
C
1
6
M
NO
5
J
K
L
4
G
H
I
9
W
X
Y
C
N
F
F
N
C
R
E
C
A
L
L
8
T
UV
7
P
R
S
#
0
O
P
E
R
H
O
L
D
TRF
A
NS
S
P
KR
L
NR
S
P
D
*
CAM
Male 15-pin
connector
Phone cord
Line In port
Phone cord
Phone port
CAUTION Do not connect the modem's 15-pin connector into a VGA port of a host computer.
