1 - 6 MC909X Integrator Guide
Getting Started
In order to start using the mobile computer for the first time:
• install the main battery
• charge the main battery and backup battery
• start the mobile computer
• configure the mobile computer.
The main battery can be charged before or after it is installed. Use one of the spare battery chargers to charge the
main battery (out of the mobile computer), or one of the cradles to charge the main battery installed in the mobile
computer.
Installing and Removing the Main Battery
Installing the Main Battery
Before using the mobile computer, install a lithium-ion battery by sliding the battery into the mobile computer as
shown in Figure 1-4.
When a battery is fully inserted in a mobile computer for the first time, upon the mobile computer’s first power up,
the device boots and powers on automatically.
Stylus Performs pen functions.
Universal Battery Charger
Adapter
Adapts the UBC for use with the Series 9000 batteries.
Wall Mounting Bracket and
Shelf Slide
Use for wall mounting applications.
Table 1-1 MC909X Accessories (Continued)
Accessory Description
NOTE Ensure the battery is fully inserted. Two audible clicks can be heard as the battery is fully inserted. A partially
inserted battery may result in unintentional data loss.
