MC9097 Configuration 6 - 13
2. Tap ok to exit.
GPS
Use the GPS tab for GPS diagnostics. The GPS tab is not a functional applications.
1. Tap Start > Settings > Personal tab > Phone icon > GPS tab.
or
Start > Phone > Tools > Options > Phone Info tab.
Figure 6-20 MC9097 Phone Window - GPS Tab
2. In the Refresh drop-down list, select a refresh time frame.
Table 6-1 Phone Info Tab Data
Item Description
PPT/DC # Lists the walkie-talkie phone number assigned to the SIM card installed in the mobile computer.
MSN 10 digit serial number of the io200 modem.
SIM ID Lists the 15 digit SIM ID. THis number is also printed on the SIM card.
Phone Model Lists the model number of the Motorola iDEN modem (io200B).
RIL Ver Lists the Radio Interface Layer (RIL) version.
RHA Ver Lists the Radio Hardware Abstraction (RHA) layer version.
FW Ver Lists the Motorola radio firmware version.
CP Ver Code Plug settings version. This defines the default modem and phone characteristics. This can
be written to remember any change to the default settings.
USR Ver User Data File that defines carrier specific default values for the modem.
NOTE This property page is for diagnostics only and is not visible by default. To display this property page, navigate
to the Windows directory using File Explorer and launch the PropertyPages.exe file. Follow the on-screen
instructions for installation. To remove the property page clean boot the device.
NOTE Setting the Refresh value enables the GPS radio and can drain the battery if left on.
