Wireless Applications 4 - 9
1. Select a channel number from the Channel drop-down list.
Figure 4-9
Ad-Hoc Settings Dialog Box
2. Tap Next. The Encryption dialog box displays. See Encryption on page 4-16 for encryption options.
Authentication
Use the Authentication dialog box to configure authentication. If you selected Ad-Hoc mode, this dialog box is not
available and authentication is set to
None by default.
Select an authentication type from the drop-down list and tap
Next. Selecting PEAP or TTLS displays the Tunneled
dialog box. Selecting
None, TLS, or LEAP displays the Encryption dialog box. See Encryption on page 4-16 for
encryption options. Table 4-7 lists the available authentication options.
Table 4-6
Ad-Hoc Channels
Band Channel Frequency
2.4 GHz 1 2412 MHz
2 2417 MHz
3 2422 MHz
4 2427 MHz
5 2432 MHz
6 2437 MHz
7 2442 MHz
8 2447 MHz
9 2452 MHz
10 2457 MHz
11 2462 MHz
5 GHz 36 5180 MHz
40 5200 MHz
44 5220 MHz
48 5240 MHz
