1 - 4 MC909X Integrator Guide
Figure 1-3 MC909X-S
Scan
Button
Exit Window
Headphone
Jack
Stylus
Strap
Battery
Release
Latch
Scan Button
Keypad
Indicator LED Bar
Power Button
Touch Screen
Microphone
Scan Button or
Walkie-Talkie Button
on MC9097-S
Exit Window
MC9090-S
MC9094-S
MC9097-S
Scan
Button
Scan Button or
Walkie-Talkie
Button on
(MC9097-S)
SIM Door
Stylus
