1 - 18 MC909X Integrator Guide
MC909X-K Strap
The strap may be moved to either the left or right side of the mobile computer to suit user preferences. To
reposition the MC909X-K strap:
1. Lift the loop end of the strap over the button.
Figure 1-14
Repositioning the MC909X-K Strap
2. Pull the loop through the connection post.
3. Remove the battery.
4. Insert the loop into the opposite connection post.
5. Place the loop over the button and pull taught.
6. Replace the battery.
To replace the handstrap:
1. Remove two screws securing the strap bracket to the device.
Loop
Button
Connection Post
