Getting Started 2 - 3
Figure 2-1 Removing the Keypad
3. Replace the keypad and re-attach using the two screws.
Figure 2-2 Installing the Keypad
4. Perform a warm boot.
SD/MMC Card Holder
Keypad
Screws
CAUTION Do not apply more than 4 in-lbs of torque when tightening the keypad screws.
