Getting Started 2 - 13
Setting the Device IP Address
By default, the cradle uses DHCP to obtain its IP address. However, if DHCP fails, the Cradle Manager can assign
an IP address.
To set the IP address:
1. Launch the MobileDox Cradle Manager on the host computer.
2. Click File > Set IP Address of Unlisted Device. The Set IP Address window appears:
Figure 2-10
Set IP Address Window
3. Enter the appropriate MAC Address and IP address.
4. Click OK.
Modifying Cradle Settings
1. Launch the MobileDox Cradle Manager on the host computer.
2. Select the name of the cradle you want to configure from the list.
3. Click Device > Modify Settings.
4. Use the General Settings tab to modify the identification settings of the cradle.
NOTE This is used if the cradle is connected to the network, but fails to appear in MobileDox. Enter the hardware
device (MAC) address to locate the cradle and assign it a new IP address.
