• Do not open the covers or move media loading lever during measuring.
15. Press the [Enter] key.
• "Wait for a while..."is displayed on the operation panel.
• The print head moves to the left.
• "Open left mainte. cover." is displayed on the operation panel.
16. Open the maintenance cover on the left of the printer.
• "Detach instrument and Set connector [ENTER]" is displayed on the operation panel.
17. While pressing the release buttons on both sides of spectrophotometer, pull it forward to remove it
from the print head.
No. Name
1 Maintenance cover
