VJ-1617H OPERATION MANUAL Before using
3-33
(2) When using 5-color set
• You can check the ink color labels for ink colors and its cartridge slots.
• Insert High-capacity ink pack adapters all the way in Ink cartridge slots.
• When a High-capacity ink pack adapter is installed, "Ink Refill **%" is displayed on Operation
panel and ink replenishment starts.
• Initial replenishment takes about 10 minutes.
• Ink filling operation and pause operation are repeated during the initial ink replenishment.
• When 100% is displayed, the initial ink replenishment is complete.
• After the initial ink replenishment is complete, "Media End" is displayed on Operation panel.
• Comply strictly with the following during ink filling.If filling is interrupted, ink will be
lost when filling is resumed.
• Do not turn OFF the printer.
• Do not unplug the power cord set of the printer.
• Do not open Front cover.
• Do not open Maintenance cover.
• Do not raise Front media loading lever (i.e., Do not lower Rear media loading
lever).
• Do not use ink packs that have little ink remaining.
No. Name
1 High-capacity pack adapter
2 Ink cartridge slots
