Before using VJ-1617H OPERATION MANUAL
3-36
2. Loosen retaining screws of Media-feed table, and slowly level the table.
3. Tighten the leveling screws of Media-feed table (2 places, both sides), and fix the table.
NOTE
• When fixing the leveling screws, hold the frame while pressuring the rubber foot, and then turn the
screw until it doesn't turn any further.
No. Name
1 Media-feed table
2 Leveling screw
1
2
1
2
3
3
