Before using VJ-1617H OPERATION MANUAL
3-44
1. Turn the printer ON.
2. In Panel setup menu, check if the "media type" for the User type you're going to use is appropriately
set.
4.3.2 Menu setup procedure
5.2.2.10 MediaType menu
• If the type of the media you have loaded differs from that of the user type you have set, the media
may not be detected properly.
3. Raise Front media loading lever (lower Rear media loading lever).
• Media-feed table is excluded from the illustration for simplicity.
4. Open the front cover.
No. Name
1 Front media loading lever
2 Rear media loading lever
No. Name
1 Front cover
To Next Page
