Before using VJ-1617H OPERATION MANUAL
3-60
NOTE
• When setting the roll media, set both sides of the media at least 5 mm away from the edge of the
pressurizing roller.
Slippage or creases may occur during printing.
8. If the edge of the roll media is set less than 5 mm from the edge of the pressurizing roller, follow the
procedure below to adjust the position of the roll media.
a. Loosen the fixing levers of the right and left roll media holders, and move the roll media to left
or right.
b. After moving the roll media, fix it with fixing levers of the right and left roll media holders.
NOTE
• Fix the roll media holders by pressing the holders to the printer.
• If you have moved the roll media to the sides, repeat the steps 5 to 7.
No. Name
1 Roll media
2 Pressurizing rollers
5mm 5mm 5mm5mm
2
1
2
1
2
1
